HOUSINGS: MIC & PHONE JACK- SURFACE MOUNTING,RECESSED & UNDER DASH
---------------------------------------------------------------------------------------------------
 FAP 08-1 with plus installed
Surface Mounted Housing (2) HOLE
Very popular item,durable and attractive metal housing for mic & phone jacks,intercom,fuses or switches etc. Made of aluminum .040 tk .Mount with (4) small screws in the corners of the flange. Phone Jack hardware not included. (3) Finishes Available: P/N FAP 08-1 black P/NFAP08-2 beige P/N FAP08-3 plain aluminum. Dimensions: W=2.9" X L= 3.56" X H= 1.06 to outer edge of flange Holes .380 dia x 1.0 BC. WEIGHT 22 GRAMS ______________________________________________________
HOUSING- Surface Mounted. Single Hole
For mic, phone jack or mics Dim:W=2.9 x L=3.56x H= 1.06 Hole dim: 3/8 dia./ key way Aluminum .040 thick- no paint. Weight: 22grams P/N FAP08-13 _______________________________________________
HOUSING- BLANK HOUSING NO HOLES. SAME HOUSING AS FAP 08-3 HOUSING. CAN BE MACHINED TO SUIT SPECIFIC NEEDS.WE CAN PROVIDE SPECIAL MACHINE WORK IF NEEDED.
Dim: W=2.9 L=3.56 H=1.06 to outer edge of flange. Weight: 25grams FAP 08-3NH Bare aluminum no finish ____________________________________________________ |
Recessed mounted mic & phone jack housing.
With this part the plugs enter form the opposite side so they are recessed and out of the way.When jacks are plugged in they are flush with the surface of the housing a real custom look with this style of housing. Made of aluminum with a powder coat finish. Comes bagged with clamp,(1) mounting screw.Less hardware. (3) Finishes: P/N FAP 08-4 black P/N FAP 08-5 beige P/N FAP 08-6 plain unpainted aluminum. Dimensions: W= 2.9 , L= 3.56" , to outer edge of flange. H= 1.06. Holes .380 dia. x 1.0 between center Weight: 32 grams Cut-out required W= 2.38 L= 3.19 add 3/8" corner radius (4) pls. Installation note: Due to the variety of different hardware it may be necessary to bend jack location, the aluminum is soft for this purpose. Best method to do so is to mount housing firmly in place so as not to deform the outer flange, then use a Phillips screw driver or old male plug placed inside of the female elliptical and carefully bend to desired location this is a common practice. ___________________________________________________
HOUSING- (3) HOLE SURFACE MOUNTED.
Has (3) 3/8 dia holes for jack. Mount (4) small screws in the flange Dimension: 3.75WIDE X 5.0 LONG X 1.06 HIGH to outer edge of flange Weight: 38 grams P/N FAP 08-15 BARE ALUMINUM NO PAINT ______________________________________________________
HOUSING- (1) HOLE SURFACE MOUNTED
FOR BOSE STYLE JACK PLUG Dim. to outside edges W=2.9 L=3.56 H= 1.06 ( hole dim. .562 dia. x .500 across the flats ) Weight: 22grams P/N FAP 08-16 aluminum no paint ___________________________________________ |
hOUSING: (4) Hole Surface Mounted Aluminim Housing. Less hardware
Dimensions: 3.75WIDE X 5.0LONG X 1.13 HIGH to outer edge of flange. Mount with (4) small screws in the side of the flange. Holes: .380 dia. x 1.0 between centers Weight: 40 grams P/N FAP 08-7 Black finish. P/N FAP 08-8 Beige finish P/N FAP 08-9 Bare Aluminum (no paint) ___________________________________________
HOUSING- Mic & Phone + Bose
(2) standard .38 dia.holes (1) Bose center hole measures .562 dia. x .500 across the flats. Dim. W=3.9 X L= 4.9 to outer edge of flange H= 1.06 Weight: 38 grams P/N FAP 08-17 Alunimun no paint ______________________________________________ |
Housing 4 Hole Recessed With this style of housing jack plugs are out of the way in the recessed housing, a real custom look. Comes with clamp bar and screws.Camp bar holds housing securely in place with (2) screws supplied.
Same as a 08-4 but has (4) .38 diameter holes. Dim. W=3.8 X L=4.9 to outer edge of flange X H= 1.06. Cutout dim. w=3.19 x L 4.25. best to add 3/8" radius in (4) corners.Weight: 61 grams (3) Finishes available: FAP 08-10 Black aluminum F/P 08-11 beige '' FAP 08-12 plain aluminum no paint FAP 08-12NH Plain Aluminum no holes. these can be custom machined if needed. _______________________________________________________ |
HOUSING: NEXUS JACK TJT-120
HOUSING: (1) HOLE for NEXUS Jack
TJT-120 FAP 08-20 BLACK FAP 08-21 BEIGE FAP08-22 ALUMINUM NO PAINT Dim:W=2.9 x L=3.56x H= 1.06 ___________________________________________________
Housing: (3) Hole for NEXUS Jack
TJT-120 (3) .875 dia. hole 3.75WIDE X 5.0LONG X 1.13 HIGH to outer edge of flange. P/N FAP08-23 ________________________________________________ |
HOUSING: (4) Hole for NEXUS Jack TJT-120
3.75WIDE X 5.0LONG X 1.13 HIGH to outer edge of flange. P/N FAP 08-24 ___________________________________________ |
Bracket- for NEXUS JTJ-120 JACK
Under the Panel
Dimensions- 2.5w x 1.5h x 1.0 deep.
(1) .875 dia. hole
Weight: 16 grams
P/N FAP 08-27 aluminum color black.
P/N FAP 08-27A same part but with 1.125 dia hole.
_______________________________________________________________________________________________________________
____________________________________________________________________________________________________________
Under the Panel
Dimensions- 2.5w x 1.5h x 1.0 deep.
(1) .875 dia. hole
Weight: 16 grams
P/N FAP 08-27 aluminum color black.
P/N FAP 08-27A same part but with 1.125 dia hole.
_______________________________________________________________________________________________________________
____________________________________________________________________________________________________________
HOUSING: NEXUS TJ-120 *
*********Can be special ordered-- not in production yet available soon*********
*********Can be special ordered-- not in production yet available soon*********
HOUSING: (1) HOLE FOR
TJ-120 JACK CONECTOR (.625 dia hole Dim:W=2.9 x L=3.56x H= 1.6 22 GRAMS ALUMINUM NO PAINT P/N FAP-29 __________________________________________ |
HOUSING: (2) HOLE FOR TJ-120 JACK CONECTOR (.625 dia hole)
Dim:W=2.9 x L=3.56x H= 1.6 22 GRAMS ALUMINUM NO PAINT P/N FAP-30 ________________________________________ |
HOUSING: (1) HOLE FOR TJ-120 JACK CONECTOR (.625 dia. hole)
Dim:3.75WIDE X 5.0LONG X 1.13 HIGH to outer edge of flange. 40 GRAMS P/N FAP-31 no paint ________________________________________________ |
HOUSING: (1) HOLE FORTJ-120 JACK CONECTOR .625 dia hole
Dim:3.75WIDE X 5.0LONG X 1.13 HIGH to outer edge of flange. 40 GRAMS P/N FAP-29 no paint _______________________________________________ |
HOUSING: UNDER THE DASH FOR MIC & PHONE ,SWITCHES, ETC.
________________________________________________________________________________________
________________________________________________________________________________________
1) Hole for either Mic or Phone Mounting Bracket
Under the Panel Dimensions- 1.5w x 1.5h x 1.0 deep. (1) hole .380 dia. Weight: 13 grams Aluminum Black finish P/N FAP 09-1 ________________________________________________ |
(2) Hole Mic & Phone Mounting Bracket
Under the Panel Dimensions: 2.3w x 1.5h x 1.0 deep. (2) holes .380 dia. x 1.0 between center Weight: 16 grams aluminum black finish. P/N FAP 09-2 ________________________________________________ |
Bracket- (4) Hole Vertical for Mic & Phone Under the Panel
Dimensions: 2.3w x 2.5h x 1.0 deep. (4) holes .380 dia. x 1.0 between centers Weight: 28 grams P/N FAP 09-4 ____________________________________________________ |
Bracket- (4) hole horizontal for Mic or Phone Under the Panel
Dimensions- 4.5w x 1.5h x 1.0 deep. (4) holes .380 dia. x 1.0 between centers Weight: 29 grams P/N FAP 09-3 ______________________________________________________ |
Bracket- for cigarette lighter reciptical Under the Panel
Dimensions- 2.5w x 1.5h x 1.0 deep. (1) .875 dia. hole Weight: 16 grams aluminum color black P/N FAP 09-5 ______________________________________________________ |
***END |
